1 Ohm 1206 Chip Resistor 1W ±1% EAM Ellon High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: EAM16FT1R00DES
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
EAM16FT1R00DES
Minimum Order Quantity:
5000
Price:
Negotiable
Standard Packaging:
5000
Delivery Time:
3-5 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Features:
High Power, Low Inductance,Anti-Sulfur
Manufacturer:
Ellon
Series:
EAM
Size:
1206
Resistance Range:
1 Ohm
Tolerance:
±1%
Power Rating:
1W
Operating Temperature Range:
-55°C To +155°C
Temperature Coefficient:
±50 Ppm/°C
Material:
Matal Film
Termination Style:
SMD
Per Reel:
5000
Type:
Fixed
Mounting Type:
Surface Mount
Package:
Tray Pack
Highlight:

1 Ohm 1206 chip resistor

,

1W high precision SMD resistor

,

RoHS compliant anti sulfurated resistor

Product Description
1 Ohm 1206 Chip Resistor 1W ±1% EAM Ellon High Precision SMD
1206 1W 1 Ohm Metal Film Chip Resistor ±1% Tolerance. This 1206 chip resistor from Ellon EAM series delivers 1 Ohm resistance with ±1% tolerance and 1W rated power, giving designers a compact surface-mount part that maintains stable performance under load and temperature variations.
Technical Specifications
ParameterSpecification
ManufacturerEllon
SeriesEAM
Size1206
Resistance Range1 Ohm
Tolerance±1%
Power Rating1W
Operating Temperature Range-55°C to +155°C
Temperature Coefficient±50 ppm/°C
MaterialMetal Film
Key Features
  • Stable 1W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±50 ppm/°C temperature coefficient maintains value stability during temperature changes
  • Metal Film element material for consistent, repeatable performance
  • Compact 1206 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. The Metal Film construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 1206 package maintains compact board layouts.
Why Choose This Part
Purchasing directly from the manufacturer ensures the EAM series is available at competitive pricing with short lead times. Every batch undergoes electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant and can include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
Application reference showing 1206 1W 1 Ohm Metal Film Chip Resistor ±1% Tolerance in circuit board implementation
Application reference: 1206 1W 1 Ohm Metal Film Chip Resistor ±1% Tolerance
