0.35m ohm 2512 Current Shunt Resistor 6W ±1% ESR Ellon High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR25F6W0M35M04G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR25F6W0M35M04G
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
4000
Delivery Time:
3-5 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Features:
High Power, Low Inductance
Manufacturer:
Ellon
Series:
ESR
Size:
2512
Resistance Range:
0.35m Ohm
Tolerance:
±1%
Power Rating:
6W
Operating Temperature Range:
-55°C To +175°C
Temperature Coefficient:
±100 Ppm/°C
Material:
MnCuSn
Termination Style:
SMD
Per Reel:
4000
Applications:
Current Sensing, Power Supplies, Motor Control, Battery Management
Highlight:

0.35m ohm 2512 current shunt resistor

,

6W high precision SMD resistor

,

RoHS compliant current shunt resistor

Product Description
0.35m ohm 2512 Current Shunt Resistor 6W ±1% ESR Ellon High Precision SMD
2512 Size 0.00035Ω (0.35m Ohm) 6W MnCuSn Metal Shunt Chip Resistor for Current Sensing. This 2512 current shunt resistor from Ellon ESR series delivers 0.35m ohm resistance with ±1% tolerance and 6W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
Manufacturer Ellon
Series ESR
Size 2512
Resistance Range 0.35m ohm
Tolerance ±1%
Power Rating 6W
Operating Temperature Range -55°C to +175°C
Temperature Coefficient ±100 ppm/°C
Material MnCuSn
Key Features
  • Stable 6W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that keeps values stable as the board heats up
  • MnCuSn element material for consistent, repeatable performance
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
  • Current Sensing
  • Power Supplies
  • Motor Control
  • Battery Management
This current shunt resistor's MnCuSn construction and stable electrical behavior help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 2512 body keeps the layout compact.
Why Choose This Part
Buying directly from the manufacturer keeps the ESR series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.
Application reference showing 2512 Size 0.00035Ω (0.35m Ohm) 6W MnCuSn Metal Shunt Chip Resistor in current sensing circuit
Application reference: 2512 Size 0.00035Ω (0.35m Ohm) 6W MnCuSn Metal Shunt Chip Resistor
