0.5mΩ(0.0005 Ohm) 2512 Current Shunt Resistor 6W ±1% ESR Ellon High Precision SMD

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR25F6W0M50M04G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR25F6W0M50M04G
Minimum Order Quantity:
5000
Price:
Negotiable
Standard Packaging:
4000
Delivery Time:
5-7 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Features:
High Power, Low Inductance
Manufacturer:
Ellon
Series:
ESR
Size:
2512
Resistance Range:
0.5mΩ(0.0005 Ohm)
Tolerance:
±1%
Power Rating:
6W
Operating Temperature Range:
-55°C To +175°C
Temperature Coefficient:
±100 Ppm/°C
Material:
MnCu
Termination Style:
SMD
Per Reel:
4000
Applications:
Current Sensing, Power Supplies, Motor Control, Battery Management
Highlight:

0.5mΩ current shunt resistor

,

2512 SMD shunt resistor 6W

,

high precision current shunt resistor

Product Description
0.5mΩ (0.0005 Ohm) 2512 Current Shunt Resistor 6W ±1%
2512 Size 0.0005Ω (0.5m Ohm) 6W Metal Shunt Chip Resistor with MnCu Material and Low Inductance for High Power Applications. This 2512 current shunt resistor from Ellon ESR series delivers 0.5mΩ(0.0005 Ohm) resistance with ±1% tolerance and 6W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
ParameterSpecification
ManufacturerEllon
SeriesESR
Size2512
Resistance Range0.5mΩ (0.0005 Ohm)
Tolerance±1%
Power Rating6W
Operating Temperature Range-55°C to +175°C
Temperature Coefficient±100 ppm/°C
MaterialMnCu
Key Features
  • Stable 6W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that keeps values stable as the board heats up
  • MnCu element material for consistent, repeatable performance
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor suits Current Sensing, Power Supplies, Motor Control, Battery Management. Its MnCu construction and stable electrical behaviour help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 2512 body keeps the layout compact.
Why Choose This Part
Buying directly from the manufacturer keeps the ESR series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.
Application reference for 2512 Size 0.0005Ω (0.5m Ohm) 6W Metal Shunt Chip Resistor
Application reference: 2512 Size 0.0005Ω (0.5m Ohm) 6W Metal Shunt Chip Resistor
Contact Us

Send your inquiry directly to us
