2mΩ(0.002 Ohm) 2512 Current Shunt Resistor 6W ±1% ESR Ellon High Precision SMD

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR25F5WR002F04G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR25F5WR002F04G
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
4000
Delivery Time:
3-5 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Features:
High Power,Low Temperature
Manufacturer:
Ellon
Series:
ESR
Size:
2512
Resistance Range:
2mΩ(0.002 Ohm)
Tolerance:
±1%
Power Rating:
6W
Operating Temperature Range:
-55°C To +175°C
Temperature Coefficient:
±100 Ppm/°C
Material:
FeCrAL
Termination Style:
SMD
Per Reel:
4000
Applications:
Current Sensing, Power Supplies, Motor Control, Battery Management
Highlight:

2mΩ current shunt resistor 6W

,

2512 SMD shunt resistor ±1%

,

high precision current shunt resistor

Product Description
2mΩ (0.002 Ohm) 2512 Current Shunt Resistor 6W ±1%
2512 Size 0.002Ω (2m Ohm) 6W 1% Tolerance Metal Shunt Resistor for Current Sensing. This 2512 current shunt resistor from Ellon ESR series delivers 2mΩ (0.002 Ohm) resistance with ±1% tolerance and 6W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Manufacturer Ellon
Series ESR
Size 2512
Resistance Range 2mΩ (0.002 Ohm)
Tolerance ±1%
Power Rating 6W
Operating Temperature Range -55°C to +175°C
Temperature Coefficient ±100 ppm/°C
Material FeCrAL
Key Features
  • Stable 6W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that maintains value stability as temperature increases
  • FeCrAL element material for consistent, repeatable performance
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor is ideal for Current Sensing, Power Supplies, Motor Control, and Battery Management systems. Its FeCrAL construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 2512 package maintains a compact layout.
Quality & Value Proposition
Sourcing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Compliance
Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
Application reference for 2512 Size 0.002Ω (2m Ohm) 6W 1% Tolerance Metal Shunt Resistor in current sensing circuit
Application reference: 2512 Size 0.002Ω (2m Ohm) 6W 1% Tolerance Metal Shunt Resistor
