0.001Ω 5930 Current Shunt Resistor 9W ±1% Ellon High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR59F9WR001F02G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR59F9WR001F02G
Minimum Order Quantity:
2000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Power Rating:
9W
Operating Temperature:
-55°C ~ +170°C
Resistance:
0.001Ω
Package Size:
15.0mm X 7.5mm
TCR:
±50ppm/°C
Tolerance:
±1%
Highlight:

0.001Ω current shunt resistor

,

9W high precision SMD resistor

,

Ellon RoHS compliant shunt resistor

Product Description
5930 Current Shunt Resistor - 0.001Ω 9W High Precision SMD
5930 0.001Ω (1m Ohm) 9W Metal Shunt Resistor with FeCrAl Alloy for High Current Measurement. This 5930 current shunt resistor from Ellon delivers 0.001Ω resistance with ±1% tolerance and 9W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
Power Rating9W
Operating Temperature-55°C ~ +170°C
Resistance0.001Ω
Package Size15.0mm x 7.5mm
TCR±50ppm/°C
Tolerance±1%
Model NumberESR59F9WR001F02G
Key Features
  • Stable 9W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±50ppm/°C temperature coefficient that keeps values stable as the board heats up
  • Compact 5930 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
  • Current sensing circuits
  • Power supplies and converters
  • Industrial control systems
  • Consumer electronics
  • Power conversion and protection circuits
Quality & Performance Benefits
This current shunt resistor features ceramic construction and stable electrical behavior to help designers meet tight tolerances in current sensing applications. The 5930 package maintains a compact layout while delivering reliable performance.
Manufacturing & Supply Advantages
Sourced directly from the manufacturer for competitive pricing with short lead times. Every batch undergoes electrical testing before packaging to ensure specified resistance and tolerance values are delivered accurately.
Packaging & Compliance
Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request.
Application reference: 5930 0.001Ω (1m Ohm) 9W Metal Shunt Resistor with FeCrAl Alloy for High Current Measurement
Application reference: 5930 0.001Ω (1m Ohm) 9W Metal Shunt Resistor with FeCrAl Alloy
