0.002Ω (2m Ohm) 5930 Current Shunt Resistor 9W 1% High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: ESR59F7WR002K02G
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
ESR59F7WR002K02G
Minimum Order Quantity:
2000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
TCR:
±75ppm/°C
Power rating:
9W
Operating temperature:
-55°C To +175°C
Tolerance:
1%
Resistance:
0.002Ω (2m Ohm)
Thermal EMF:
<2µV/°C
Highlight:

0.002Ω current shunt resistor

,

9W high precision shunt resistor

,

SMD RoHS compliant shunt resistor

Product Description
0.002Ω (2m Ohm) 5930 Current Shunt Resistor 9W 1% High Precision SMD
5930 0.002Ω (2m Ohm) 9W Karma Alloy Metal Shunt Resistor for High-Precision Current Sensing. This 5930 current shunt resistor from Ever Ohms delivers 0.002Ω (2m Ohm) resistance with 1% tolerance and 9W rated power, giving designers a compact surface-mount part that maintains stable performance under load and temperature variations.
Technical Specifications
TCR±75ppm/°C
Power Rating9W
Operating Temperature-55°C to +175°C
Tolerance1%
Resistance0.002Ω (2m Ohm)
Thermal EMF<2µV/°C
Model NumberESR59F7WR002K02G
Key Features
  • Stable 9W rated power handling for demanding circuits
  • 1% tolerance for dependable measurement accuracy
  • Low ±75ppm/°C temperature coefficient that maintains value stability during board heating
  • Compact 5930 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor is ideal for current sensing applications, power supplies, industrial control systems, and consumer electronics. The ceramic construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the compact 5930 package maintains efficient board space utilization.
Manufacturing Advantages
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every production batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments comply with RoHS and REACH regulations and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing customized for your project requirements.
Application reference showing 5930 0.002Ω (2m Ohm) 9W Karma Alloy Metal Shunt Resistor in high-precision current sensing circuit
