0.005R (5mOhm) 2512 Current Shunt Resistor 2W (at 70°C) Ellon High Precision SMD

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR25F2W5R005F04G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR25F2W5R005F04G
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Resistance Tolerance:
±1%
Nominal Resistance:
0.005R (5mOhm)
Operating Temperature:
-55°C~+175°C
Rated Power:
2W (at 70°C)
Temperature Coefficient:
≤±50ppm/°C
Package Size:
2512 (6.4mm×3.2mm×0.95mm)
Highlight:

0.005R 2512 current shunt resistor

,

5mOhm high precision SMD resistor

,

2W current shunt resistor 70°C

Product Description
Ellon ESR25F2W5R005F04G 2512 Current Shunt Resistor
Ellon ESR25F2W5R005F04G 2512 0.005R(5mOhm) 2W ±1% FeCrAl Metal Shunt Chip Resistor. This 2512 current shunt resistor from Ellon delivers 0.005R (5mOhm) resistance with standard tolerance and 2W (at 70°C) rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
Parameter Specification
Resistance Tolerance ±1%
Nominal Resistance 0.005R (5mOhm)
Operating Temperature -55°C~+175°C
Rated Power 2W (at 70°C)
Temperature Coefficient ≤±50ppm/°C
Package Size 2512 (6.4mm*3.2mm*0.95mm)
Model Number ESR25F2W5R005F04G
Key Features
  • Stable 2W (at 70°C) rated power handling for demanding circuits
  • Low ≤±50ppm/°C temperature coefficient that keeps values stable as the board heats up
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor suits current sensing, power supplies, industrial control and consumer electronics. Its ceramic construction and stable electrical behaviour help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 2512 body keeps the layout compact.
Why Choose This Part
Buying directly from the manufacturer keeps the series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.
Application reference of Ellon ESR25F2W5R005F04G 2512 0.005R(5mOhm) 2W ±1% FeCrAl Metal Shunt Chip Resistor
