0.002R (2mOhm) 2512 Current Shunt Resistor 5W 1% Ellon High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ellon
Certification: RoHS / REACH
Model Number: ESR25F5WR002F04G
Product Details
Place of Origin:
Made in China
Brand Name:
Ellon
Certification:
RoHS / REACH
Model Number:
ESR25F5WR002F04G
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Temperature coefficient:
±25ppm/℃
Tolerance:
1%
Resistance value:
0.002R (2mOhm)
Package size:
2512 (6.4mm × 3.2mm)
Material:
FeCrAl Alloy
Power rating:
5W
Highlight:

2512 current shunt resistor 5W

,

high precision SMD shunt resistor

,

RoHS compliant current shunt resistor

Product Description
Ellon ESR25F5WR002F04G 2512 Current Shunt Resistor
0.002Ω (2mΩ) ultra-low resistance 2512 metal shunt chip resistor with 5W high power rating and 1% precision tolerance. This compact surface-mount component maintains stable performance under varying load and temperature conditions.
Technical Specifications
Resistance Value0.002Ω (2mΩ)
Tolerance1%
Power Rating5W
Temperature Coefficient±25ppm/℃
Package Size2512 (6.4mm × 3.2mm)
MaterialFeCrAl Alloy
Model NumberESR25F5WR002F04G
Key Features
  • Stable 5W rated power handling for demanding circuit applications
  • 1% tolerance ensures dependable measurement accuracy
  • Low ±25ppm/℃ temperature coefficient maintains stability across temperature variations
  • FeCrAl alloy element material provides consistent, repeatable performance
  • Compact 2512 SMD footprint compatible with high-density reflow assembly
  • RoHS and REACH compliant for lead-free manufacturing processes
Applications
Ideal for current sensing applications, power supplies, industrial control systems, and consumer electronics. The FeCrAl alloy construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits while maintaining compact board layouts.
Manufacturer Direct Advantages
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing prior to packaging, guaranteeing that specified resistance and tolerance values are delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments comply with RoHS and REACH standards, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
Application reference: Ellon ESR25F5WR002F04G 2512 Metal Shunt Chip Resistor with 0.002Ω ultra-low resistance in circuit implementation
