6.8Ω 2512 Chip Resistor 2W ±1% Ever Ohms High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH2512F6R80E04S
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH2512F6R80E04S
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Power rating:
2W
Resistance:
6.8Ω
Operating temperature:
-55°C To +155°C
Max voltage:
200V
Tolerance:
±1%
Package size:
6.35mm × 3.2mm
Highlight:

6.8Ω 2512 chip resistor 2W

,

high precision SMD resistor

,

RoHS compliant thick film resistor

Product Description
CRH2512F6R80E04S 2512 6.8Ω 2W High Precision Chip Resistor
This high-power 2512 chip resistor from Ever Ohms delivers 6.8Ω resistance with ±1% tolerance and 2W rated power, providing designers with a compact surface-mount component that maintains stable performance under varying load and temperature conditions.
Technical Specifications
Power Rating2W
Resistance6.8Ω
Operating Temperature-55°C to +155°C
Maximum Voltage200V
Tolerance±1%
Package Size6.35mm × 3.2mm
Model NumberCRH2512F6R80E04S
Key Features
  • Stable 2W rated power handling for demanding circuit applications
  • ±1% tolerance for reliable measurement accuracy
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS and REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 2512 package maintains a compact layout.
Quality & Manufacturing Benefits
Sourced directly from the manufacturer, this resistor series offers competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, ensuring the specified resistance and tolerance values are consistently delivered.
Packaging & Compliance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
CRH2512F6R80E04S 2512 6.8Ω 2W High Power Resistor application reference
Application reference: CRH2512F6R80E04S 2512 6.8Ω 2W High Power Resistor with ±1% Tolerance
