470Ω 2512 Chip Resistor 2W @ 70℃ ±1% Ever Ohms High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH2512F470RE04Z
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH2512F470RE04Z
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Resistance:
470Ω
Max Voltage:
200V
Package size:
2512 (6.4×3.2mm)
TCR:
±100ppm/℃
Tolerance:
±1%
Rated Power:
2W @ 70℃
Highlight:

470Ω 2512 chip resistor 2W

,

high precision SMD resistor

,

thick film chip resistor RoHS

Product Description
470Ω 2512 Chip Resistor 2W @ 70℃ ±1% High Precision SMD
EVER OHMS CRH2512F470RE04Z 2512 Thick Film Chip Resistor 470Ω 2W High Power with ±1% Tolerance. This 2512 chip resistor from Ever Ohms delivers 470Ω resistance with ±1% tolerance and 2W @ 70℃ rated power, giving designers a compact surface-mount part that maintains stable performance under load and temperature variations.
Technical Specifications
Parameter Specification
Resistance 470Ω
Max Voltage 200V
Package Size 2512 (6.4×3.2mm)
TCR ±100ppm/℃
Tolerance ±1%
Rated Power 2W @ 70℃
Model Number CRH2512F470RE04Z
Key Features
  • Stable 2W @ 70℃ rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100ppm/℃ temperature coefficient that maintains value stability as temperature increases
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 2512 package maintains a compact layout.
Manufacturing Advantages
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments comply with RoHS and REACH standards and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
Application reference: EVER OHMS CRH2512F470RE04Z 2512 Thick Film Chip Resistor 470Ω 2W High Power with ±1% Tolerance
Application reference: EVER OHMS CRH2512F470RE04Z 2512 Thick Film Chip Resistor
