22 Ω 2512 (6.4 mm × 3.2 mm) Chip Resistor 2 W (@70 °C) ±1% Ever Ohms High Precision SMD

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH2512F22R0E04Z
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH2512F22R0E04Z
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Tolerance:
±1%
TCR:
±100 Ppm/°C
Nominal Resistance:
22 Ω
Package Size:
2512 (6.4 Mm × 3.2 Mm)
Rated Power:
2 W (@70 °C)
Operating Temperature:
-55 °C ~ +155 °C
Highlight:

22 Ω 2512 chip resistor 2W

,

high precision SMD resistor

,

thick film chip resistor ±1%

Product Description
CRH2512F22R0E04Z 22 Ω 2W High Power Thick Film Chip Resistor
CRH2512F22R0E04Z 22 Ω 2W High Power Thick Film Chip Resistor with ±1% Tolerance. This 2512 (6.4 mm × 3.2 mm) chip resistor from Ever Ohms delivers 22 Ω resistance with ±1% tolerance and 2 W (@70 °C) rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Tolerance±1%
TCR±100 ppm/°C
Nominal Resistance22 Ω
Package Size2512 (6.4 mm × 3.2 mm)
Rated Power2 W (@70 °C)
Operating Temperature-55 °C ~ +155 °C
Model NumberCRH2512F22R0E04Z
Key Features
  • Stable 2 W (@70 °C) rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that maintains value stability during board heating
  • Compact 2512 (6.4 mm × 3.2 mm) SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical behavior help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the compact 2512 (6.4 mm × 3.2 mm) body enables space-efficient layouts.
Manufacturer Advantages
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every production batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly, available in standard reel quantities for SMT production lines. All shipments comply with RoHS and REACH standards and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing customized for your project requirements.
CRH2512F22R0E04Z 22 Ω 2W High Power Thick Film Chip Resistor application reference
Application reference: CRH2512F22R0E04Z 22 Ω 2W High Power Thick Film Chip Resistor
