220 kΩ 2512 (6.4 mm × 3.2 mm) Chip Resistor 2 W (at 70 °C ambient) Ever Ohms

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH2512F220KE04Z
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH2512F220KE04Z
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Nominal Resistance:
220 KΩ
Maximum Working Voltage:
200 V
Package Size:
2512 (6.4 Mm × 3.2 Mm)
Temperature Coefficient:
±100 Ppm/°C
Rated Power:
2 W (at 70 °C Ambient)
Resistance Tolerance:
±1%
Highlight:

220 kΩ 2512 chip resistor

,

2W high power chip resistor

,

thick film chip resistor with warranty

Product Description
220 kΩ 2512 (6.4 mm × 3.2 mm) Chip Resistor 2 W (at 70 °C ambient)
CRH2512F220KE04Z 220 kΩ 2 W ±1% Tolerance High-Power Thick Film Chip Resistor for Industrial Applications. This 2512 (6.4 mm × 3.2 mm) chip resistor from Ever Ohms delivers 220 kΩ resistance with standard tolerance and 2 W (at 70 °C ambient) rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Nominal Resistance 220 kΩ
Maximum Working Voltage 200 V
Package Size 2512 (6.4 mm × 3.2 mm)
Temperature Coefficient ±100 ppm/°C
Rated Power 2 W (at 70 °C ambient)
Resistance Tolerance ±1%
Model Number CRH2512F220KE04Z
Key Features
  • Stable 2 W (at 70 °C ambient) rated power handling for demanding circuits
  • Low ±100 ppm/°C temperature coefficient that maintains value stability during board heating
  • Compact 2512 (6.4 mm × 3.2 mm) SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. The ceramic construction and stable electrical behavior help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the compact 2512 (6.4 mm × 3.2 mm) body enables space-efficient layouts.
Quality & Performance Advantages
Sourcing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly, with standard reel quantities optimized for SMT production lines. All shipments comply with RoHS and REACH standards and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
CRH2512F220KE04Z 220 kΩ 2 W ±1% Tolerance High-Power Thick Film Chip Resistor application reference
