1.8Ω 2512 Chip Resistor 2W (@70℃) Ever Ohms High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH2512F1R80E04S
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH2512F1R80E04S
Minimum Order Quantity:
4000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Resistance Tolerance:
±1%
Temperature Coefficient:
±100ppm/℃
Nominal Resistance:
1.8Ω
Max Working Voltage:
200V
Rated Power:
2W (@70℃)
Package Size:
2512 (6.4mm×3.2mm)
Highlight:

1.8Ω 2512 chip resistor 2W

,

high precision SMD resistor

,

RoHS compliant thick film resistor

Product Description
CRH2512F1R80E04S 2512 1.8Ω 2W High Precision Chip Resistor
This 2512 chip resistor from Ever Ohms delivers 1.8Ω resistance with ±1% tolerance and 2W (@70℃) rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Resistance Tolerance±1%
Temperature Coefficient±100ppm/℃
Nominal Resistance1.8Ω
Max Working Voltage200V
Rated Power2W (@70℃)
Package Size2512 (6.4mm × 3.2mm)
Model NumberCRH2512F1R80E04S
Key Features
  • Stable 2W (@70℃) rated power handling for demanding circuits
  • Low ±100ppm/℃ temperature coefficient maintains value stability during temperature fluctuations
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS and REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing applications, power supplies, industrial control systems, and consumer electronics. The ceramic construction and stable electrical characteristics help designers maintain tight tolerances in current sensing, power conversion, and protection circuits, while the 2512 package maintains a compact layout.
Quality & Manufacturing Advantages
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every production batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Compliance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments comply with RoHS and REACH standards and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
Application reference for CRH2512F1R80E04S 2512 1.8Ω 2W ±1% Tolerance High Power Thick Film Chip Resistor
