0.24Ω 1206 Chip Resistor 0.5W ±1% Ever Ohms High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH1206FR240P05Z
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH1206FR240P05Z
Minimum Order Quantity:
5000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Nominal resistance:
0.24Ω
Mounting type:
Surface Mount Device (SMD)
Package size:
1206 (3.2mm × 1.6mm)
Operating temperature:
-55℃ ~ +155℃
Power rating:
0.5W
Tolerance:
±1%
Highlight:

0.24Ω 1206 chip resistor 0.5W

,

high precision SMD resistor RoHS

,

thick film chip resistor ±1%

Product Description
0.24Ω 1206 Chip Resistor 0.5W ±1% High Precision SMD
CRH1206FR240P05Z 1206 0.24Ω 0.5W SMD Resistor High Power Thick Film Chip Resistor. This 1206 chip resistor from Ever Ohms delivers 0.24Ω resistance with ±1% tolerance and 0.5W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Nominal Resistance 0.24Ω
Mounting Type Surface Mount Device (SMD)
Package Size 1206 (3.2mm × 1.6mm)
Operating Temperature -55℃ to +155℃
Power Rating 0.5W
Tolerance ±1%
Model Number CRH1206FR240P05Z
Key Features
  • Stable 0.5W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Compact 1206 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical behavior help designers meet tight tolerances in current sensing, power conversion, and protection circuits, while the 1206 package maintains a compact layout footprint.
Quality & Reliability
Sourced directly from the manufacturer, this resistor series offers competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, ensuring the specified resistance and tolerance values are consistently delivered.
Packaging & Compliance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
CRH1206FR240P05Z 1206 0.24Ω 0.5W SMD Resistor application reference and product illustration
Application reference: CRH1206FR240P05Z 1206 0.24Ω 0.5W SMD Resistor High Power Thick Film Chip Resistor
