2.00Ω ±1% 1206 Chip Resistor 0.5W Ever Ohms High Precision SMD RoHS Compliant

Place of Origin: Made in China
Brand Name: Ever Ohms
Certification: RoHS / REACH
Model Number: CRH1206F2R00P05S
Product Details
Place of Origin:
Made in China
Brand Name:
Ever Ohms
Certification:
RoHS / REACH
Model Number:
CRH1206F2R00P05S
Minimum Order Quantity:
5000
Price:
Negotiable
Standard Packaging:
Tape and reel
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
Large volume available
Specifications
Rated power:
0.5W
TCR:
±200 To ±400ppm/°C
Resistance:
2.00Ω ±1%
Max working voltage:
200V
Case size:
1206 / 3216 Metric, ~3.2mm × 1.6mm × 0.55mm
Operating temperature:
−55°C To +155°C
Highlight:

2.00Ω 1206 chip resistor

,

0.5W high precision SMD resistor

,

RoHS compliant thick film resistor

Product Description
2.00Ω ±1% 1206 Chip Resistor 0.5W High Precision SMD
1206 2Ω 0.5W High Power Thick Film Chip Resistor for Current Sensing and Power Applications. This 1206 chip resistor from Ever Ohms delivers 2.00Ω ±1% resistance with standard tolerance and 0.5W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Parameter Specification
Rated power 0.5W
TCR ±200 to ±400ppm/°C
Resistance 2.00Ω ±1%
Max working voltage 200V
Case size 1206 / 3216 metric, ~3.2mm * 1.6mm * 0.55mm
Operating temperature −55°C to +155°C
Model Number CRH1206F2R00P05S
Key Features
  • Stable 0.5W rated power handling for demanding circuits
  • Low ±200 to ±400ppm/°C temperature coefficient that maintains value stability during board heating
  • Compact 1206 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 1206 package maintains compact board layouts.
Why Choose This Part
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every production batch undergoes comprehensive electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automated pick-and-place assembly, in standard reel quantities optimized for SMT production lines. All shipments comply with RoHS and REACH regulations and include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
1206 2Ω 0.5W High Power Thick Film Chip Resistor application in current sensing and power circuits
Application reference: 1206 2Ω 0.5W High Power Thick Film Chip Resistor for Current Sensing and Power Applications
