Quality 2m ohm（0.002 ohm） 1225 Chip Resistor 3W ±1% HTE Walter High Precision SMD RoHS Compliant factory

2m ohm（0.002 ohm） 1225 Chip Resistor 3W ±1% HTE Walter High Precision SMD RoHS Compliant

Name: 2m ohm（0.002 ohm） 1225 Chip Resistor 3W ±1% HTE Walter High Precision SMD RoHS Compliant
Brand: Shenzhen Shun Hai Technology Co., Ltd.
SKU: HTE2512M3W0R002F
Price: Negotiable USD
Availability: InStock

Place of Origin: Made in China

Brand Name: Walter

Certification: RoHS / REACH

Model Number: HTE2512M3W0R002F

Product Details

Place of Origin:

Made in China

Brand Name:

Walter

Certification:

RoHS / REACH

Model Number:

HTE2512M3W0R002F

Minimum Order Quantity:

4000

Price:

Negotiable

Standard Packaging:

4000

Delivery Time:

5-8 work days

Payment Terms:

T/T

Supply Ability:

Large volume available

Specifications

Features:

High Power, Low Inductance

Name:

SMD Chip Resistor

Manufacturer:

Walter

Series:

HTE

Size:

1225

Resistance Range:

2m Ohm（0.002 Ohm）

Tolerance:

±1%

Power Rating:

Operating Temperature Range:

-55°C To +155°C

Temperature Coefficient:

±100 Ppm/°C

Material:

MnCu Alloy

Termination Style:

SMD

Per Reel:

4000

Type:

Fixed

Mounting Type:

Surface Mount

Package:

Tray Pack

Applications:

Current Sensing, Power Supplies, Motor Control, Battery Management

Highlight:

2m ohm 1225 chip resistor

3W HTE Walter SMD resistor

high precision wide terminal resistor

Product Description

1225 SMD Chip Resistor 0.002Ω Metal Foil Resistors 3W

This 1225 chip resistor from Walter HTE series delivers 2m ohm (0.002 ohm) resistance with ±1% tolerance and 3W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.

Technical Specifications

Name	SMD Chip Resistor
Manufacturer	Walter
Series	HTE
Size	1225
Resistance Range	2m ohm (0.002 ohm)
Tolerance	±1%
Power Rating	3W
Operating Temperature Range	-55°C to +155°C
Temperature Coefficient	±100 ppm/°C

Key Features

Stable 3W rated power handling for demanding circuits
±1% tolerance for dependable measurement accuracy
Low ±100 ppm/°C temperature coefficient that maintains value stability during temperature fluctuations
MnCu alloy element material for consistent, repeatable performance
Compact 1225 SMD footprint suitable for high-density reflow assembly
RoHS / REACH compliant construction for lead-free manufacturing

Applications

This chip resistor is ideal for current sensing, power supplies, motor control, and battery management systems. The MnCu alloy construction and stable electrical behavior help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the 1225 package maintains a compact layout.

Quality & Reliability

Sourced directly from the manufacturer, the HTE series offers competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, ensuring the specified resistance and tolerance values are precisely delivered.

Packaging & Compliance

Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request.
