Quality 4m ohm（0.004 ohm） 0508(1.2mm*2.0mm) Chip Resistor 1W ±1% HTE Walter High Precision SMD factory

4m ohm（0.004 ohm） 0508(1.2mm*2.0mm) Chip Resistor 1W ±1% HTE Walter High Precision SMD

Name: 4m ohm（0.004 ohm） 0508(1.2mm*2.0mm) Chip Resistor 1W ±1% HTE Walter High Precision SMD
Brand: Shenzhen Shun Hai Technology Co., Ltd.
SKU: HTE0805M1W0R004F
Price: Negotiable USD
Availability: InStock

Place of Origin: Made in China

Brand Name: Walter

Certification: RoHS / REACH

Model Number: HTE0805M1W0R004F

Product Details

Place of Origin:

Made in China

Brand Name:

Walter

Certification:

RoHS / REACH

Model Number:

HTE0805M1W0R004F

Minimum Order Quantity:

5000

Price:

Negotiable

Standard Packaging:

5000

Delivery Time:

3-5 work days

Payment Terms:

T/T

Supply Ability:

Large volume available

Specifications

Features:

High Precision, High Power, Low Temperature Ticket, Low Inductance

Name:

1W SMD Resistor

Manufacturer:

Walter

Series:

HTE

Size:

0508(1.2mm*2.0mm)

Resistance Range:

4m Ohm（0.004 Ohm）

Tolerance:

±1%

Power Rating:

Operating Temperature Range:

-55°C To +155°C

Temperature Coefficient:

±100 Ppm/°C

Material:

MnCu Alloy

Per Reel:

5000

Applications:

Current Sensing, Power Supply, Motor Control, Battery Management, Frequency Converter, 5G Base Station, LED Lighting,

Highlight:

1W high precision chip resistor

0508 size SMD resistor

4m ohm wide terminal resistor

Product Description

4mΩ (0.004Ω) 0508 Chip Resistor - 1W ±1% HTE Series

MnCu Alloy 1W SMD Resistor High Power 4mΩ Resistor designed for 5G base stations. This 0508 (1.2mm × 2.0mm) chip resistor from Walter HTE series delivers 4mΩ (0.004Ω) resistance with ±1% tolerance and 1W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.

Technical Specifications

Product Name	1W SMD Resistor
Manufacturer	Walter
Series	HTE
Size	0508 (1.2mm × 2.0mm)
Resistance Range	4mΩ (0.004Ω)
Tolerance	±1%
Power Rating	1W
Operating Temperature	-55°C to +155°C
Temperature Coefficient	±100 ppm/°C

Key Features

Stable 1W rated power handling for demanding circuits
±1% tolerance for dependable measurement accuracy
Low ±100 ppm/°C temperature coefficient maintains stable values during temperature fluctuations
MnCu alloy element material ensures consistent, repeatable performance
Compact 0508 (1.2mm × 2.0mm) SMD footprint suitable for high-density reflow assembly
RoHS / REACH compliant construction for lead-free manufacturing

Applications

This chip resistor is ideal for current sensing, power supply systems, motor control, battery management, frequency converters, 5G base stations, and LED lighting applications. The MnCu alloy construction and stable electrical characteristics help designers meet tight tolerances in current sensing, power conversion, and protection circuits, while the compact 0508 footprint maintains efficient board space utilization.

Quality & Manufacturing Advantages

Sourced directly from the manufacturer, the HTE series offers competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, ensuring the specified resistance and tolerance values are consistently delivered.

Packaging & Compliance

Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
